D9U003VB3-0101_046/65
1.5 Symbols and Labels on the Product
READ INSTRUCTIONS FOR USE
2X T1AH ANTI-SURGE FUSE
(250 V, TYPE 5X20MM)
2X T2AH ANTI-SURGE FUSE
(250 V, TYPE 5X20MM)
(MODEL WITH Accumulator BACK-UP)
ALTERNATING CURRENT (AC)
ACTIVATION GO BUTTON
DEVICE IS CONNECTED TO MAINS IF GREEN INDICATOR ON THE CONTROL
PANEL IS LIT
PROTECTION AGAINST ACCIDENTS DUE TO ELECTRICAL CURRENT – TYPE B
APPLIED PARTS
DOUBLE INSULATION (CLASS II EQUIPMENT)
WARNING
CE MARK OF CONFORMITY WITH EU REGULATION
SCU MAINS SWITCH
–: ON (CONNECTED TO THE MAINS SUPPLY)
O: OFF (DISCONNECTED FROM MAINS SUPPLY)
DEVICE IS CONNECTED TO MAINS WHEN GREEN PART OF THE SWITCH IS
REVEALED.
Accumulator POWER SWITCH
–: ON (Accumulator ACTIVATED)
O: OFF (Accumulator NOT ACTIVATED)
SCU MAINS SWITCH
_______________
Accumulator POWER SWITCH
WEEE SYMBOL (RECYCLE AS ELECTRONIC WASTE,
DO NOT PUT INTO THE HOUSEHOLD WASTE)
ONLY SUITABLE FOR INDOOR USE
