Linksys LRT224 User Manual

5
Getting Started with the Router Configuration
Linksys
Connect/ Disconnect: If the WAN type is PPPoE or PPTP, this button
will appear. Click Disconnect to cut the
connection from ISP server. Click Connect to
re-dial to the server.
DMZ Status:
NOTE:
It is recommended to designate the configurable port on the
LRT224 as a DMZ port. Go to Device Configuration > Network and
check the Enable DMZ box.
IP Address: IP address of DMZ port.
DMZ Host: Private IP of DMZ host.
Firewall Settings
This section displays the current firewall settings:
SPI (Stateful Packet Inspection): Default configuration is On.
DoS (Denial of Service): Default configuration is On.
Block WAN Request: Default configuration is On.
Remote Management: Default configuration is Off.
Access Rule: The number of access rules configured
in the router.
VPN Settings
Tunnel(s) Used: Number of tunnels configured.
Tunnel(s) Available: Number of tunnels the router supports.
OpenVPN Status
Tunnel(s) Used: Number of OpenVPN tunnels configured.
Tunnel(s) Available: Number of OpenVPN tunnels the router supports.
Log Setting Status
This section displays the following information:
Syslog Server: Indicates whether Syslog server is activated.
Email Log: Indicates whether Email Log is activated.

Linksys LRT224 Specifications

General

Color	black
Wi-Fi Mesh System	no
Band Technology	dual
Frequency Band	not applicable
Ethernet Standard	10/100/1000
Gigabit Ethernet Speed	yes
Firewall	spi
Ports	rj-45
LAN Ports	4
Built In Modem	no

Weight and Dimensions

Height	1.58 inches
Width	5.15 inches
Net Weight	1.78 pounds
