Linksys
• Falling Event—Select an event to be performed when a falling event
is triggered.
STEP 4 Click Apply. The RMON alarm is saved to the Running Configuration file.
Interface Statistics
The Interface Statistics page displays traffic statistics per port. The refresh rate
of the information can be selected.
This page is useful for analyzing the amount of traffic that is both sent and
received and its dispersion (Unicast, Multicast, and Broadcast).
To display Ethernet statistics and/or set the refresh rate, do the following:
STEP 1 Click System Status > Interface Statistics.
STEP 2 Enter the parameters.
Interface Statistics
• Interface—Select the specific interface for which Ethernet statistics are to
be displayed.
• Refresh Rate—Select the time period that passes before the interface
Ethernet statistics are refreshed. The available options are as follows:
• No Refresh—Statistics are not refreshed.
• 15 Sec—Statistics are refreshed every 15 seconds.
• 30 Sec—Statistics are refreshed every 30 seconds.
• 60 Sec—Statistics are refreshed every 60 seconds.
The Receive Statistics area displays information about incoming packets.
• Unicast Packets—Good Unicast packets received.
• Multicast Packets—Good Multicast packets received.
• Broadcast Packets—Good Broadcast packets received.
• Error Packets—Packets with errors received.
The Transmit Statistics area displays information about outgoing packets.
• Total Octets—Octets transmitted, including bad packets and FCS octets,
but excluding framing bits.
• Unicast Packets—Good Unicast packets transmitted.
• Multicast Packets—Good Multicast packets transmitted.
• Broadcast Packets—Good Broadcast packets transmitted.
• To clear or view statistics counters, do the following:
• Click Refresh to refresh the counters on the page.
• Click Clear to clear the selected interfaces counters.
• Click View All to see all ports on a single page.
