• Inventory—Whether Inventory TLV is transmitted.
STEP 2 The message at the top of the page indicates whether the generation
of the LLDP MED Network Policy for the voice application is
automatic or not (see LLDP Overview). Click on the link to change the
mode.
STEP 3 To associate additional LLDP MED TLV and/or one or more user-
defined LLDP MED Network Policies to a port, select it, and click Edit.
STEP 4 Enter the parameters:
• Port—Select the interface to configure.
• LLDP MED Status—Enable/disable LLDP MED on this port.
• Available Optional TLVs—Select the TLVs that can be published by the
device by moving them from the Advertise Optional TLVs list.
• Available Network Policies—Select the LLDP MED policies to be
published by LLDP by moving them from the Available Network Policies
list. These were created in the LLDP MED Network Policy page. To include
one or more userdefined network polices in the advertisement, you must
also select Network Policy from the Available Optional TLVs.
NOTE:
The following fields must be entered in hexadecimal characters in the exact
data format that is defined in the LLDP-MED standard (ANSI-TIA-1057_final_
for_publication.pdf):
• Location Coordinate—Enter the coordinate location to be published
by LLDP.
• Location Civic Address—Enter the civic address to be published
by LLDP.
• Location (ECS) ELIN—Enter the Emergency Call Service (ECS) ELIN
location to be published by LLDP.
STEP 5 Click Apply. The LLDP MED port settings are written to the Running
Configuration file.
LLDP Local Information
To view the LLDP local port status advertised on a port:
STEP 1 Click Configuration > Port Management > Discovery - LLDP > LLDP
Local Information.
STEP 2 Select the desired port from the Port list.
This page displays the following groups of fields (the actual fields displayed
depend on the optional TLVs selected to be advertised):
Global
• Chassis ID Subtype—Type of chassis ID. (For example, the MAC address.)
• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC
address, the MAC address of the device appears.
• System Name—Name of device.
• System Description—Description of the device (in alpha-numeric format).
• Supported System Capabilities—Primary functions of the device, such as
Bridge, WLAN AP, or Router.
• Enabled System Capabilities—Primary enabled function(s) of the device.
• Port ID Subtype—Type of the port identifier that is shown.
• Port ID—Identifier of port.
• Port Description—Information about the port, including manufacturer,
product name and hardware/software version.
Management Address
Displays the table of addresses of the local LLDP agent. Other remote
managers can use this address to obtain information related to the local
device. The address consists of the following elements:
• Address Subtype—Type of management IP address that is listed in the
Management Address field; for example, IPv4.
• Address—Returned address most appropriate for management use.
• Interface Subtype—Numbering method used for defining the
interface number.
• Interface Number—Specific interface associated with this
management address.
MED Information
• Capabilities Supported—MED capabilities supported on the port.
• Current Capabilities—MED capabilities enabled on the port.
