Linksys
• Community—Select from the pull-down the community string of the trap
manager. Community String names are generated from those listed in the
Community page.
• Notification Filter—Select to enable filtering the type of SNMP
notifications sent to the management station. The filters are created in
the Notification Filter page.
• Filter Name—Select the SNMP filter that defines the information
contained in traps (defined in the Notification Filter page).
STEP 3 Click Apply. The SNMP Notification Recipient settings are written to
the Running Configuration file.
SNMP v3 Notification Recipients
• To define a recipient in SNMPv3:
STEP 1 Click Configuration > System Management > SNMP > V3 Notification
Recipients.
This page displays recipients for SNMPv3.
STEP 2 Enter the fields:
• Recipient—Select whether to specify the remote log server by IP address
or server name.
• IP Version—Select either IPv4 or IPv6.
• IPv6 Address Type—Select the IPv6 address type (if IPv6 is used). The
options are:
• Link Local—The IPv6 address uniquely identifies hosts on a single
network link. A link local address has a prefix of FE80, is not routable,
and can be used for communication only on the local network. Only
one link local address is supported. If a link local address exists on the
interface, this entry replaces the address in the configuration.
• Global—The IPv6 address is a global Unicast IPV6 type that is visible
and reachable from other networks.
• Link Local Interface—Select the link local interface (if IPv6 Address Type
Link Local is selected) from the pull-down list.
• Recipient IP Address/Name—Enter the IP address or server name of
where the traps are sent.
• UDP Port—Enter the UDP port used to for notifications on the
recipient device.
• Notification Type—Select whether to send traps or informs. If both are
required, two recipients must be created.
• User Name—Select from the drop-down list the user to whom SNMP
notifications are sent. In order to receive notifications, this user must be
defined on the SNMP User page, and its engine ID must be remote.
• Security Level—Select how much authentication is applied to the packet.
NOTE:
The Security Level here depends on which User Name was selected. If
this User Name was configured as No Authentication, the Security Level
is No Authentication only. However, if this User Name has assigned
Authentication and Privacy on the User page, the security level on this
screen can be either No Authentication, or Authentication Only, or
Authentication and Privacy.
The options are:
• No Authentication—Indicates the packet is neither authenticated
nor encrypted.
• Authentication—Indicates the packet is authenticated but not encrypted.
• Privacy—Indicates the packet is both authenticated and encrypted.
• Notification Filter—Select to enable filtering the type of SNMP
notifications sent to the management station. The filters are created in
the Notification Filter page.
• Filter Name—Select the SNMP filter that defines the information
contained in traps (defined in the Notification Filter page).
STEP 3 Click Apply. The SNMP Notification Recipient settings are written to
the Running Configuration file.
Logs
This section describes the Logs feature, which enables the device to generate
multiple independent logs. It covers the following topics:
• Log Management
• Remote Log Servers
• RAM Log
• Flash Memory Log
