{a,b,c,…} – A choice among a, b, c, …
IP – IP Address in the form of x.x.x.x, where x between 0 and 255. For example 10.1.2.100
Port – TCP/UDP Port number (0-65535). It can be specified in decimal of hex format.
UserID – User ID as appeared in a URL; up to 63 characters
FQDN – Fully Qualified Domain Name, such as “sip.linksys.com:5060”, or “109.12.14.12:12345”. It can
contain up to 63 characters
Phone – A phone number string, such as 14081234567, *69, *72, 345678, or a generic URL such as
1234@10.10.10.100:5068, or jsmith@linksys.com. It can contain up to 39 characters.
ActCode – Activation code for a supplementary service, such as *69. It can contain up to 11 characters.
PhTmplt – A phone number template. Each template may contain 1 or more patterns separated by a “,”.
White space at the beginning of each pattern is ignored. “?” and “*” represent wildcard characters. It can
contain up to 39 characters. Examples: “1408*, 1510*”, “1408123????, 555?1”.
RscTmplt – A template of SIP Response Status Code, such as “404, 5*”, “61?”, “407, 408, 487, 481”. It
can contain up to 39 characters.
CadScript – A mini-script that specifies the cadence parameters of a signal. Up to 127 characters.
Syntax: S
1
[;S
2
], where S
i
=D
i
(on
i,1
/off
i,1
[,on
i,2
/off
i,2
[,on
i,3
/off
i,3
[,on
i,4
/off
i,4
[,on
i,5
/off
i,5
[,on
i,6
/off
i,6
]]]]]) and is known
as a section, on
i,j
and off
i,j
are the on/off duration in seconds of a segment and i = 1 or 2, and j = 1 to 6. D
i
is the total duration of the section in seconds. All durations can have up to 3 decimal places to provide 1
ms resolution. The wildcard character “*” stands for infinite duration. The segments within a section are
played in order and repeated until the total duration is played. Examples:
Example 1: Normal Ring
60(2/4)
Number of Cadence Sections = 1
Cadence Section 1: Section Length = 60 s
Number of Segments = 1
Segment 1: On=2s, Off=4s
Total Ring Length = 60s
Example 2: Distinctive Ring (short,short,short,long)
60(.2/.2,.2/.2,.2/.2,1/4)
Number of Cadence Sections = 1
Cadence Section 1: Section Length = 60s
Number of Segments = 4
Segment 1: On=0.2s, Off=0.2s
Segment 2: On=0.2s, Off=0.2s
Segment 3: On=0.2s, Off=0.2s
Segment 4: On=1.0s, Off=4.0s
