Rev: 05.23.2017 Page 12 Ground Control 3.0 Service Manual
3. Disconnect the rear sensor harness from the connector on the rear sensor (Fig. 18A).
Fig. 19
4. Remove the screws (Fig. 19D), mounting plate (Fig. 19C) and sensor (Fig. 19B) assembly from the
crossmember (Fig. 19A).
Fig. 18
A
A
B
C
D
