Lippert Components PSX1 User Manual

Rev:11.08.19 Page 17 CCD-0001573-08
Fig. 1
A
E
F
H
G
B
C
D
J
I
K
Callout Description
A Up Arrow - Scrolls up through the menu on LCD.
B Down Arrow - Scrolls down through the menu on LCD.
C Enter - Activates modes and procedures indicated on LCD.
D
Retract - Places leveling system into retract mode.
- Press and hold down for 1 second to initiate Auto Retract.
E LCD Display - Displays procedures and results.
F Auto Level - Places leveling system into auto level mode.
G Front Jack Button - Activates front jacks in manual mode.
H Left Jack Button - Activates left jacks in manual mode.
I Right Jack Button - Activates right jacks in manual mode.
J Rear Jack Button - Activates rear jacks in manual mode.
K Power Button - Turns leveling system on and off.
Touch Pad Diagram

Lippert Components PSX1 Specifications

General

Brand	Lippert Components
Model	PSX1
Category	Lifting Systems
Language	English
