-23-
4. TRANSPORT
4.1. Transport position
Danger!
In order to secure the masonry saw against rolling away, the masonry saw may only be
transported in transport position.
The transport position includes:
 Masonry saw is disconnected from power and the power plug (Pos. 8) is hung in the holder
 Parking brake on the steerable wheel (Pos. 15) is activated
 Saw table (Pos.11) is moved to the stop in the machine and secured on the rear with the
linchpin (Pos. 10)
 Clamping lever of the cutting height adjustment (pos. 7) is tightened
 Checking the locking of the saw arm The locking (Pos. 18) must be on the frame
 Fold in the clamping lever for feed unit (only DTS 901-V)
 Water tank (pos. 13) must be emptied
4.2. Move with the construction crane
Danger!
The masonry saw may only be transported or moved in transport position.
Danger!
Only use undamaged slinging equipment with sufficient carrying capacity.
Personnel should never remain under hanging loads.
Hang masonry saw with slinging equipment with sufficient carrying capacity on the crane eye
(Pos. 12).
 Name expert instructors before the lifting process
 Only use suitable lifting devices with sufficient load capacity
 Lift carefully and pay attention to the centre of gravity
 Always keep an eye on the masonry saw
 Secure loads reliably. Use suitable attachment points
 When recommissioning, follow the operating manual
