Lissmac DTS 901-V - Page 35

-35-
Pos. Art.-Nr. Description Specification Stk.
spare part
recommendation
1 690879 Mount
1
2 690887 Saw arm 1
3 691194 Gear case 1
4 690880 Hood cplt. 1
4.1 209850 Guard stopper captive screw 1
5 680660 Mist protection 1 X
6 607524 Pump strainer 1
7 613071 Saw blade flange 1 X
8 607490 Eccentric 1
9 610082 Cover 1
10 206168 Splash guard 1
11 607510 Reinforcement plate 1
12
6
81307 Water pan 1
13 607312 Pillow block 1
14 607511 Reinforcement 1
15 613070 Saw blade shaft 1
16 610099 Pan locking bar 1
17 607519 Plug fuse 1
18 607526 Switch holder 1
19 280003 Wheel, solid rubber 2 X
20 300081 Washer - steel DIN 125 A 21,0 2
21 203457 Wheel, solid rubber 1 X
22 681708 Electro motor 7.5 kW 7,5 kW 1
23 203663 Flange sleeve 1
24 790185 Saw blade 1
25 206195 Sliding plug 2
27 610222 Water tap 1 X
28 200237 Bow grip, plastic, black D=6,5 1
29 300248 Washer – steel DIN 125 A 6,4
30 300833 Lock nut BIW V-Form 6,0
31 280183 Pan locking bar 20 mm ST-KA 20 2
32 280041 Plug fuse 8x41x47 1
33 200324 C-link chain DIN 5685 26x3 0,2m
34 300172 Hexagonal screw DIN 933 6x20
35 202653 Key ring VA Ø30 mm 1
36 403226 Submersible pump 230V 230V 1 X
37 200195 PVC hose 13X3,5 3,17m
38 300054 Single-ear clamp
39 206977 Y screw-in bushing X
40 280108 Geka hose piece 1
41 280104 Geka coupling 1
42 403169 Check nut M 25x1,5 mm
43 403167 Cable fitting M 32x1,5 mm
44 280165 PVC hose 10X2 1,8m
45 200578 Single-ended spanner SW 46 1 X
46 280199 Single-ended spanner SW 13 1 X
47 201824 Tension spring 2
48 300652 Eye bolt M 8x60
49 300291 Washer - steel DIN 7349 8,4
50 300273 Hexagon nut DIN 934 8,0
51 403263 Switch cover 1
51.1 403166 Cable fitting M 25x1,5 mm 2
51.2 403168 Check nut M 25x1,5 mm 2
51.3 403055 Cable fitting M 16x1,5 mm 1
51.4 403062 Check nut M 16x1,5 mm 1
51.5 400060 Phase inverter plug 32-A 1 X
51.6 403243 Line, flexible 1
