-37-
Pos. Art.-Nr. Description Specification Stk.
spare part
recommendation
115 690885 Boom tupe cplt. 1
116 690661 Crank handle 1 X
117 607513 Table extension 1
118 622657 Washer – steel 1 X
119 607539 Drive wheel 1 X
120 607540 Sprocket 1
121 607541 Sprocket 1
122 607538 Drive shaft 1
123 607537 Crankshaft 1
124 607534 Streching roller holder inside 1
125 607535 Streching roller holder outside 1
126 607533 Spacer bush 1
127 607527 Spacer bush 1
128 206941 Compression spring 1 X
129 607518 Bearing cover 1
130 201535 Flange sleeve 3
131 611753 Bronze bush 1
132 210378 Wire rope D=4mm 1
133 203553 Sliding plug 2
134 280050 Ball bearing 6204.2RS C-LAGER 2
135 300327 Washer – steel DIN 6340 10,5
136 607512 Reinforcing angle 2
137 300046 Safety screw
138 300132 Safety screw SK 6x16
139 280026 Ball bearing 6200.2RS C-LAGER 2
140 206227 Roller chain 1/2" X 5/16" 1
141 280034 Chain push-on link 1
142 203024 Ball lever M12 DIN99 1
143 280082 Cylinder grip M12 D = 31 mm 1
144 300806 Sealing ring DIN 472 D = 30
145 300179 Washer – steel DIN 125 A 17,0
146 300239 Hexagonal screw DIN 933 10x50
147 360151 Hexagonal screw DIN 933 10x80
148 300332 Shim ring DIN 988 20x28x1,0
149 300333 Shim ring DIN 988 20x28x0,5
151 301252 Dowel pin ISO 8752 5x36
152 300504 Dowel pin ISO 8748 6x 40
153 300306 Shim ring DIN 988 16x22x1,0
154 300385 Coach bolt DIN 603 12x70 1
155 300576 Washer - steel DIN 7349 13,0
157 300003 Eyebolt DIN 580 8,0
158 607571 Safety bolt 1
159 301393 Carriage bolt DIN 603 12x40
160 680294 Movable bearing 1
160.1 607562 Stud 1
160.2 607561 Guide roller 1 X
160.3 206300 Ball bearing 6003.2RS C-LAGER 2 X
160.4 300080 Hexagon nut DIN 934 12,0 2
160.5 300166 Washer – steel DIN 125 A 13,0 2
161 680295 Fixed bearing 1
161.1 607563 Stud 1
161.2 607561 Guide roller 1
161.3 206300 Ball bearing 6003.2RS C-LAGER 2
161.4 300080 Hexagon nut DIN 934 12,0 2
161.5 300166 Washer – steel DIN 125 A 13,0 2
161.6 607560 Spacer bush 1
162 690898 Table 1
