Lite-Check INSPECTOR 930 - Overview

LITE-CHECK INSPECTOR 930
8
Overview
The LITE-CHECK INSPECTOR 930 has the following components:
ITEM DESCRIPTION
REMOTE CCONTROL ANTENNA Antenna for use with the remote control.
BLUETOOTH ANTENNA
Antenna used with a Bluetooth enabled tablet.
DIGITAL DISPLAY Displays messages on the tester status and results.
KEYPAD See page 7 for individual buttons
ALARM SPEAKER Speaker sounds different alarms for test failure.
EMERGENCY AIR CONNECTOR Port for connecting emergency air to the tester.
SERVICE AIR CONNECTOR Port for connecting Service air to the tester.
7-WAY CABLE SOCKET Cable socket for 7-way cable
SIDE 7-WAY CABLE SOCKET Cable socket for 7-way cable. (Used for cable testing)
ALARM SPEAKER
KEYPAD
EMERGENCY AIR CONNECTOR SERVICE AIR CONNECTOR
7-WAY CABLE SOCKET
DIGITAL DISPLAY
REMOTE CONTROL ANTENNA
BLUETOOTH ANTENNA
SIDE 7-WAY SOCKET
