LITE-CHECK INSPECTOR 930
28
Electrical Output Test
1. Press the “TRACTOR OUTPUT TEST” button.
2. Plug the 7-way cable from
the tractor into the front port on the INSPECTOR 930.
3. Operate the tractor’s electrical functions. The corresponding LED on the
INSPECTOR 930 will light and the output voltage will appear on the digital
display.
Battery/Alternator Test
1. Press the “TRACTOR OUTPUT TEST” button.
2. Plug the 7-way cable from
the tractor into the front port on the INSPECTOR 930.
3. Turn the tractor ignition button to the ON position. The AUXIL circuit LED will
light and the battery voltage will appear on the digital display.
4. Start the tractor’s engine and the alternator voltage will be appear on the digital
display. Erratic voltage may indicate a faulty alternator.
Air Output Test
NOTE: The INSPECTOR 930 may be powered ON or OFF for this test.
1. Connect the tractor’s air line glad hands to the INSPECTOR 930’s glad hands.
2. Activate the tractor’s emergency air and view the PSI reading on the
EMERGENCY air gauge.
3. Press the tractors brake pedal to view the PSI reading on the SERVICE air
gauge.
Tractor Testing
In addition to the trailer testing, some test may be performed on the tractor as well.
These tests are the Electrical Output Test, the Battery/Alternator Test, and the Air
Output Test
TRACTOR
OUTPUT
TEST
CABLE TEST
TRACTOR
OUTPUT
TEST
CABLE TEST
