To Cock the Dorsal (Chest Cushion) Drop - Automatic
1) Rotate the Selector Knob (No. 1) to “D” to Select the Dorsal (Chest Cushion) drop
2) Step on white strip to activate the auto cocking drop
CAUTION: The drop cushion tension should be checked and tested before adjusting patient. KEEP FINGERS
AWAY FROM BOTTOM OF CUSHION TO AVOID PINCHING.
3) Adjust the tension on the drop by turning the Tension Control Knob (Refer to Page 7 for Tension Adjustment Instructions).
To Cock the Lumbar Cushion Drop - Automatic
1) Rotate the Selector Knob (No. 1) to “L” to Select the Lumbar (Lumbar Cushion) drop
2) Step on white str`ip to activate the auto cocking drop
CAUTION: The drop cushion tension should be checked and tested before adjusting patient. KEEP FINGERS
AWAY FROM BOTTOM OF CUSHION TO AVOID PINCHING.
3) Adjust the tension on the drop by turning the Tension Control Knob (Refer to Page 7 for Tension Adjustment Instructions).
Page 12
Pelvic Drop - Automatic
To cock the Pelvic Drop:
1) Rotate the Selector Knob (Pg. 8, No. 1) to “P” to Select the Pelvic drop
2) Step on white strip to activate the auto cocking drop
CAUTION: The drop cushion tension should be checked and tested before adjusting patient.
KEEP FINGERS AWAY FROM BOTTOM OF CUSHION TO AVOID PINCHING.
3) Adjust the tension on the drop by turning the Tension Control Knob (Refer to Page 7 for Tension Adjustment Instructions).
Note- Table is capable of performing a combination of drops - see Selector Knob Letter Reference Chart below.
C - Cervical Drop DC - Dorsal & Cervical Drops
D - Dorsal Drop LD - Lumbar & Dorsal Drops
L - Lumbar Drop PL - Pelvic & Lumbar Drops
P - Pelvic Drop CP - Cervical & Pelvic Drops
Selector Knob Letter Reference Chart
Automatic Cocking Drops
