Pelvic Auto Axial Distraction
# 1 Auto Mode On / Off Button
# 2 Auto Mode Indicator Light
Auto Axial Distraction (Optional)
To Turn Auto Axial Distraction “On”
1) Locate the Auto Mode On / Off Button (#1) and depres. Once button has been pressecd the Auto Mode
Indicator Light will illuminate to show that the auto feature is on.
To Turn Auto Axial Distraction “Off”
2) Locate the Auto Mode On / Off Button (#1) and depres. Once button has been pressecd the Auto Mode
Indicator Light will darken to show that the auto feature is off.
# 1 AAD Activation Button
Auto Axial Distraction (Optional)
To Extend & Retract Pelvic Cushion
1) Once Automatic axial distraction is turned “on” locate the AAD Activation Button (#1) located n the Telescoping
T-Bar. Simply press AAD Activation Button (#1) to extend the pelvic cushion and releae button to retract.
Page 20
