1 Service
Service Manual
10
1 Service
SMART CONTROL MODULE
VENT DAMPER
IGNITOR
GAS VALVES
COMBUSTION
FEEDBACK BOARD
AIR AND GAS DAMPER MOTORS
COMFORT
CONTROL BOARD
BAS BOARD
0-10V OUTPUT TO
BOILER PUMP
ALARM CONTACTS
SEQUENCER / BUILDING
MANAGEMENT SYSTEM
RUN TIME CONTACTS
LOUVER RELAY
BOILER RATE OUTPUT
PUMP RELAY BOARD
BOILER PUMP
CONTACTOR
SYSTEM PUMP
CONTACTOR
HWG PUMP
CONTACTOR
DISPLAY PANEL
PC INTERFACE
BLOWER
Control outputs
