Service Manual
23
1 Service (continued)
Advanced Setup Screen
Figure 1-10 Advanced Setup Screen
Menu
Parameter Name
(as shown on the LCD screen)
Min Max Default
Value Value Value
Freeze Protection; Pump On -22 45 45
Freeze Protection; Burner On -22 45 37
Freeze Protection; Burner Off -22 45 5
Anti-Cycling Time 0 40 10
Anti-Cycling Diff 0 54 1
Controlling Sensor 0 4 2
Inlet Control Time Delay 0 21:10 0
Minimum Boiler Rate (%)
MIN Modulation
100 MIN
Table 1F Advanced Setup (This table lists control module parameters; use the sub-tab under the Setup tab to
access them.)
ADVANCED SETUP
