2. Loosen the floating head's fastening screws as shown in photo 2, then remove the
lower assembly from the torch head as shown in Photo 3.
3. Carefully remove the torch by removing the mounting screws located on the side of the torch
assembly as shown in photo 3.
PHOTO 2
PHOTO 3
TORCH
MOUNTING
SCREWS (2)
Maintenance... Page 3
