Reference 55-85
User manual
115
System settings
Connections
Select yes or no for Subwoofer.
If no subwoofer is connected, the front speakers
additionally transmit the sound parts intended for
the subwoofer as far as possible.
Proceed to Distance to left hand front speaker.
Set the distance between the left front speaker
and your listening position in 10 cm steps.
Measure the distances from your listening position
to the front, surround, and centre speakers
respectively. The digital audio decoder calculates
delay times from this for the loudspeaker signals,
so that these reach the listener simultaneously.
Proceed to the respective other speakers (right
front speaker, left surround speaker, right
surround speaker, centre speaker and subwoofer)
and also
The selected speaker will be coloured blue.
After setting the distance to the subwoofer.
Proceed to Adjust speaker level.
100Hz 90Hz 100Hz
100Hz 100Hz
...
Sound com-
ponents
Connect subwoofer
Please specify here whether you want to
additionally connect a subwoofer for very
good bass reproduction.
no yes
Proceed withBack with
Connect
subwoofer
4,0m 3,0m
4,0m
2,0m 2,0m
3,9m
0.1 m 4.0 m 10.0 m
...
Sound com-
ponents
Distance to left front speaker
Please enter the distance of the left front
speaker from your listening position here.
Proceed withBack with
Distance to
left front
speaker
Adjust the volume for the speaker.
Proceed to next speaker or
select speakers manually.
For balanced audio reproduction all speakers should
be set to the same volume level. A noise signal will
be reproduced automatically on each speaker in
succession. Adjust every speaker to equal perceived
volume from your listening position. The selected
speaker will be coloured blue.
After adjustment of the last speaker.
Proceed to Subwoofer phase.
Switch a station or a DVD player playing music to music
playback.
Test both values (0º and 180º) and select the one
with which you get a clearer bass reproduction
from your listening position.
Back: Finish wizard.
This ends the sound components wizard for connecting
and setting up a speakers system.
0dB 0dB
0dB
0dB 0dB
0dB
-12 dB 0 dB +12 dB
...
Sound com-
ponents
Adjust speaker level
You hear a sound from every speaker one after
another. But you can also select the speakers
manually with the menu control buttons
up/down. Set the volume for the respectively
active speaker shown in blue so that you get
approximately the same volume impression
from all the speakers.
Proceed withBack with
Adjust
speaker level
...
Sound com-
ponents
Subwoofer phase
Here you can reverse the phase of your subwoofer. Test both values in
music reproduction and then select the one with which you get a better
bass reproduction.
Finish wizard with
Back with
0° 180°
Subwoofer
phase
