Fieldbook) E1) User’s) Guide)
27
2.1.4. Right View
Fieldbook E1 Right View
Item
Description
1. DC-jack
Connects the device to an power adapter to
supply continuous power during use and battery
recharging.
2. Programmable
function buttons
F1, F2, F3
Allow you to assign specific functions to a button.
The table below shows the default key
assignments.
3. Secondary
function button
Activates / deactivates the secondary function of
the F1-F3 buttons
