12
10 20 30 40 50 60 70 80 90 100MM
0
1
Numbering for installation sequence
Well done!
Work on a surface that is as flat as possible, as this will make it easier to set the rail.
RAIL ASSEMBLY
Read through all the assembly instructions
before starting assembly, then follow the
instructions step by step as you work.
Now it is time to assemble the rail. Follow
the assembly steps carefully, and adopt an
ergonomically correct posture when working.
Work on a surface that is as flat as possible,
as this will make it easier to set the rail.
WARNING! Heavy lifting! Risk of injury.
Two people are always required to help with
heavy lifting.
WARNING! Risk of crushing injury.
Wear protective gloves and handle the motor
carefully when placing it on the motor shelf.
