Read through all the set-up instructions
before starting to set up, then follow the
instructions step by step as you work.
Numbering for installation sequence
Well done!
The saw head is assembled on delivery of the sawmill, except for the motor and the handle and crank.
Follow the instructions below to complete sawmill assembly before initial start-up. Assembly work begins
with the crank and ends by connecting the throttle cable and installing the sawmill motor. Follow the
installation instructions and take care with the assembly work.
Crank complete
Crank disc
Nut
Shaft
Tab washer
Handle tube
Spring
Crank
Lock device
Handle
Washer
