Logosol B751 - Technical Data

8
LOGOSOL B751
RAIL COMPONENT
Rail length, standard 5.75 m
Rail length, extension 1140 mm
Track width 800 mm
Overall width 850 mm
Height 230 mm
Weight (5.75 m rail) 195 kg
SAW CARRIAGE
Length 900 mm
Width 1975 mm
Height 170 cm
Weight 178 kg
Volume, water reservoir 7.5 litres
Feed rate Manual
CAPACITY
Max. log diameter 750 mm
Max. sawing width 600 mm
Effective saw length (standard) 4.8 m
BANDSAW BLADE
Type and size 3843x33 pitch 22 mm
Band wheel diameter 500 mm
Band wheel, rotational speed 1000 v/min
Saw blade, speed 28 m/s
SAW MOTOR(S)/ENGINE
Electric motor drive 4.5 kW (weight: 30 kg) or 8 kW (weight: 40 kg)
Petrol engine Briggs & Stratton 13 hp (weight: 30 kg) or 18 hk (weight: 34 kg)
Volume, fuel tank 5 litres
NOISE LEVEL/VIBRATIONS
Equivalent sound pressure level at ear of operator 1) 88.4 dB(A)
Sound power level (estimated) 2) 109.4 dB(A)
Vibration level in handle 3) <2.5 m/s{1>2
1) The typical distribution measurement for equivalent sound pressure level is a standard deviation of 2 dB(A)
2) The typical distribution measurement for sound power level is a standard deviation of 3 dB(A)
3) The typical distribution measurement for vibration level in the handles is 1 m/s
2
TECHNICAL DATA
