25
B751
The saw head is partly assembled when supplied. The
rail bar tipping wheels must be installed as soon as the
saw head has been placed on the rail. After installing
the tipping wheels, to ensure proper functioning of
the sawmill the machine must be finally assembled
and adjusted as described in the adjustment sequence
provided in the manual.
SAW HEAD WEIGHT: 178 KG
It is important to adjust the saw head before starting to ensure satisfactory
sawing and the correct functioning of the sawmill. Carefully follow the
adjustment sequence! Certain adjustments affect other machine settings.
IMPORTANT!
SAW HEAD
It is now time to mount the saw head on the rail.
Well done!
