Logosol F2+ - Chainsaw Mount Assembly

3
2
4
4525-010-2000
37
LOGOSOL F2+
The saw carriage can be retrotted with vibration-damping basic crank feeding and bar nose steering. This
gives a more comfortable forward feed of the saw carriage. It also spares the cutting equipment and gives
higher accuracy when taking wide saw cuts.
Fit the Logosol nuts through the
track in the carriage. Tighten the
chainsaw into place by using the
chainsaw’s guide bar nuts under
the plate.
Push the carriage onto the guide rail
with the guide bar in the direction of
the log beds.
Always hold the chainsaw
when it is on the guide rail.
Never leave the chainsaw
on the guide rail when the
engine is on.
Unscrew the two guide bar nuts
from the chainsaw and remove
the guide bar cover.
Remove the bark grips, but leave
the bolts in place.
Ret the guide bar cover, but
replace the guide bar nuts with
Logosol nuts.
Only CE-approved
chainsaws with two
guide bar nuts may be
used togther with the
Logosol F2+.
