38
When the sawmill is placed directly
on the ground, the surface must
be rm and level enough to drive a
regular passenger car on.
Fit a board under each log lifter.
The boards must be of good
quality, and at least 28x145 mm
and 1.5 m long.
The boards must extend at least
0.5 m out from the long legs.
The Logosol F2+ must not
lean more than 5 degrees
in any direction.
Risk of overturning. The
Logosol F2+ must not be
used unless the feet are
xed to the underlying
surface or to boards.
Risk that the saw unit
slides off the guide rail.
When bolting the Logosol
F2+ to a concrete oor,
asphalt surface or similar
surface, a rubber underlay
should be placed under
each foot in order to
prevent vibration damage
to the sawmill.
Secure the logs with
wedges or reliable straps.
Example of a log table for long-
term set-up. Log ladders of steel
are available as accessories for the
Logosol F2+.
Example of a temporary log table.
SITING
min. 0.5 m
