27
THIS MANUAL IS PROPRIETY OF ECOWIND by LOMBARDINI - ALL FORMS OF REPRODUCTION, PARTIAL OR OTHERWISE, IS STRICTLY PROHIBITED
G
B
Fig. 37
4 Bended the wiring cable CE to gas pipe , half plastic band FP supplied, as showed in g. 36
5 Reassemble the plastic cover condenser CC complete the wiring connection half to connector PK (fan) and SS (pressure
switch) see g. 37. Ensure the plastic cover condenser CC to condenser C half bolts preserved V + R.
Fig. 38
CC
PK
SS
Fig. 39
CC
6 Complete gas condenser installed (rear cab) with gas pipes on back see g. 38
3 - ASSEMBLY AND INSTALLATION
