3 - ASSEMBLY AND INSTALLATION
Step Description
6 After fastening the pipes and cables under the cab oor, proceed with the tube bundle towards the condenser. (Attached
previously) g. 96.
7 Continue attaching the pipes on the outside, boring through the rear of the cab using a 3.5 mm bit, and inserting the
steel/rubber clamps FG around the pipes. Fasten using the supplied self-threading screws g 96.
Step Description
8 Pipe and wiring, at the nished installation on the oor and back cab g. 97
To Next Page
