55
THIS MANUAL IS PROPRIETY OF ECOWIND by LOMBARDINI - ALL FORMS OF REPRODUCTION, PARTIAL OR OTHERWISE, IS STRICTLY PROHIBITED
G
B
1 2
3
8
6
9
10
4
5
7
11
12
13
OR
E
Ff
FR
T10
G6
G10
Vt
Fig. 109
Fig. 111Fig. 110
Fig. 113Fig. 112
T6
OR
SPLIT CLOSING
3 - ASSEMBLY AND INSTALLATION
Step Description
1 Connect the SPLIT/EXTENSION cable connections by joining the FRAMATOME FR connectors (see g. 110).
Cut rubber hoses T6 and T10 to the right size g. 112.
Insert the couplings and clic clamps (g. 111) referring to page 32÷36 for the torque.
Close the cooling circuit, inserting the ttings G6 and G10 into the expansion valve E, and fasten (g. 113) using the
ange Ff, screw Vt and washer (g. 113).
LEGEND
1 Condensation drainage pipe
2 Union G10 90° FL
3 OR G10
4 Clic clamp 185
5 Union G6 90° FL
6 OR G6
7 Clic clamp 140
8 Insulating mastic
9 Diffuser
10 Diffuser support
11 Valve ange
12 Ø 6 Washer
13 TCEI M 6x16 Screw
Step Description
2 Before tightening the ange on the anged unions g. 113, make sure that you have inserted (if not already done) the
supplied OR G6 and G10 (see g. 112).
