Secondary parameters
909.4119.9-02 - 33 -07.19
16 Secondary parameters
Call up the secondary parameters by pressing
button 19 for 2 sec.
Set the desired secondary parameter by turn-
ing control knob 14.
A description of the secondary parameters is
provided in the following table.
Conrm the secondary parameter by pressing
control knob 14.
The parameter value ashes.
Change the value of a parameter by turning
control knob 14.
Store the change by pressing control knob 14.
Press button 19 to terminate a change with-
out storing or to exit the secondary parameter
menu.
Code Secondary parameters
Standard
value
Setting range
Mode
TIG
Elec-
trode
StE
Start energy 50 % 1 - 200 % x
Hot start energy 125 % 1 - 200 % x
Stt
Start time 0.1 s 0 - 99.9 s x
Hotstart time 1.0 s 0 - 99.9 s x
StS Start slope time 0.5 s 0 - 99.9 s x
PuO Pulse Option
OFF OFF - On
x x
2.E Second energy 50 % 1 - 200 % x x
PuF Pulse frequency 3.0 Hz 0.1 Hz - 5 kHz x x
Pub Pulse duty cycle (% of welding current I1) 50 % 1 - 99 % x x
dAF Arc Force 100 % 0 - 200 % x
AEd Arc end detection 100 % 0 - 200 % x x
Tab. 1: Secondary parameters
