Technical data
- 40 - 07.19909.4119.9-02
Technical data Units
MicorSTICK 180 CP /
RC CP (115V)
MicorSTICK 180 CP /
RC CP (230V)
Input power S
1
(max. current) kVA 4.0 4.4
Mains
Mains voltage (50/60 Hz) 1~ V 115 230
Mains frequency Hz 50 - 60
Positive mains tolerance % 15 15
Negative mains tolerance % 15 15
Mains connection cable mm² 3 x 2.5
Mains plug without Isolated ground socket
Current consumption I
1 no-load
A 0.2 0.3
Mains fuse A/tr 25 16
Power factor (at I
2
max.
) cos φ 0.99 0.99
Power factor λ (at I
2
max) 0.99 0.99
Max. permissible system impedance Zmax
in acc. with IEC 61000-3-11/12
mΩ
530 851
Recommended generator performance kVA
8 8
Machine
Protection class (EN 60529) IP 23S 23S
Insulation class F F
Cooling method F F
Noise emission dB(A) <70 <70
Dimensions and weights
Dimensions (LxWxH) mm 360 x 130 x 215 360 x 130 x 215
Weight with mains cable kg 6,2 6,2
*) measured at 40° C environmental temperature
ED = Switch-on duration
