Pc-Boards
- 42 - 02.20909.2710.1-06
Schematic
MAPRO
DS-ERW
DMR1 DMR2
X5 X3
X3 X4
8 10
X2 X1
X8 X8
X7-1
X7-2
X8-1
X8-2
8 8
In addition to the two DMR boards, the water valves are also connected the DS-ERW. Depending on the
active torch (feed one or two), the water cooling circuit is also switched over.
