Pc-Boards
- 39 -02.20 909.2710.1-06
7.15 Pc-board DK-GLCL3
The pc-board DK-GLCL3 is for connecting/wiring the secondary rectifier diodes.
Functions
– connecting diodes
– impulse smoothng
– diode protection
Picture pc-board DK-GLCL3
Fig. 27: Pc-board DK-GLCL3
Schematic
D3
D2
D1
X1
Fig. 28: schematic welding rectifier
