LORCH V Series - NEFI3 x32 Pc-board; NEFI3 x32 Functions; NEFI3 x32 Board Layout

page 22
Pc-board NEFI3x32
The pc-board NEFI3x32 is the mains lter for the V30 mobile.
Functions
- mains lter
Picture pc-board NEFI3x32
connector designation
KL1
KL2
KL2
mains input L1
mains input L2
mains input L3
KL4
KL5
KL6
mains output L1
mains output L2
mains output L3
