Lorentz PSk3-15 User Manual

LORENTZ CONNECTED 9392 LORENTZ CONNECTED
EN EN
11. 3 LORENTZ Global & PS Commander
For remote monitoring and management,
LORENTZ oer a cloud based platform for PSk3
and other LORENZT products. This is designed to
work eectively and economically for customers
managing one device to customers managing
thousands of devices.
A PS Commander is installed close to the PSk3
system. The Commander acts as a cellular gateway
to send data from the PSk3 to the LORENTZ
Global secure platform. Settings changes and
congurations can also be sent from LORENTZ
Global to the PSk3 system.
Each user can congure alerts so that LORENZT
Global pro-actively informs them of any events on
the PSk3 system. Users can log on at anytime via
a web browser to see all of their LORENTZ pump
systems in an intuitive management interface.
LORENTZ Global provides proactive monitoring and
full management of your you systems anywhere in
the world.
The LORENTZ Global service is a pay per month per
managed device service that includes unlimited
platform licensing and all cellular and data costs
You can login to LORENTZ Global at https://global.
lorentz.de using your standard partnerNET
credentials or try the demo account that is available.
Figure 58: LORENTZ Global view of installation site Figure 59: LORENTZ Global view of system details
11 LORENTZ CONNECTED
The LORENTZ CONNECTED portfolio ensures that
technicians and customers have the information
they need to manage their water system. LORENTZ
CONNECTED oers a range of features for
conguring, monitoring and managing LORENTZ
products.
For local conguration, managment and monitoring
this is done via Bluetooth® connection from the
PSk3 controller to LORENTZ Assistant app running
on an Android™ device such as a smartphone or
tablet.
For remote management and monitoring PSk3
can be connected to LORENTZ cloud based
monitoring and managment platform – LORENTZ
Global. A PS Commander is installed as a
gateway to communicate via Bluetooth® with the
PSk3 controller and the cloud based LORENTZ
Global application servers. Viewing of data and
conguration of the PSk3 system is availabel from
any web browser any where in the world.
11.1 PSk3 data access and data logging
In additional to using operational and sensor data for
pump control, the PSk3 controller also stores data
for analysis and performance reporting. Operating
data and key performance data is stored in the PSk3
controller and is accessed by using the LORENTZ
Assitant app. Both real time data (Actual Data) and
Stored data are available from the controller via
Bluetooth® connection to the LORENTZ Assitant
app. This connection is available within Bluetooth®
range of the PSk3 controller, typically within 10
metres (30 feet)
11.2 LORENTZ Assistant
LORENTZ Assistant app runs on the Android™
operating system which is found in many smart
phones and tablets.
LORENTZ Assistant app can be used by installers,
technicians or customers to view system data, look
at pump performance and change congurations.
The app is free to use and has dierent proles
available to ensure only qualied users are able to
access certain functions.
LORENTZ Assitant app is available on the Google Play
Store.
Figure 57: LORENTZ Assistant Android™ App
