Technical Specifications20
20.1.6 Storage & Archive
Storage 1× security-grade HDD (2.5” SATA, non-upgradable)
or
1× microSD card
Maximum Capacity 1× 1TB SATA HDD (2.5” SATA, non-upgradable) or
1× microSD card (up to 128 microSD Class 10
supported)
Storage Priority HDD (1× 1TB); microSD / USB flash drive: 1×
128MB
Backup Media USB flash drive, HDD & network
Backup File Format LF / MP4
20.1.7 Connectivity
Cloud Connection P2P connectivity
Supported Operating Systems Windows™
Mac OSX
Remote Software Lorex Cirrus mobile app
Email Notification Text with snapshot
Instant Smartphone & Tablet Support iPad®, iPhone®, Android™
System Configuration Full setup configuration over network
Ports Programmable by user
Network Protocol HTTP, IPv4, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP,
DHCP, DNS, PPPOE, DDNS, FTP
Network Interface 10/100 Base-TX, RJ-45
Network Bit Rate Max. 32Mbps total
20.1.8 General
Power Consumption 3W (no HDD installed)
Supply Voltage 100VAC-240VAC, 12VDC, 2A, 50/60Hz
Unit Weight (lbs / kg) 2.6lbs / 1.2kg (without hard drive)
Unit Dimensions 2.4 × 7.1 × 7.4” / 60 × 180 × 187mm
Operating Temperature 14° ~ 131°F / –10° ~ 55°C
Humidity 10 ~ 90% RH
20.1.9 Recording Resolution (Pixels) & Maximum Speed (FPS — Frames per second)
1080p 720p
6ch
Total
72fps 90fps
Per channel
12fps 15fps
As our products are subject to continuous improvement, Lorex Corporation and its subsidiaries re-
serve the right to modify product design, specifications, and prices without notice and without in-
curring any obligation. E&OE
#LX400109; r. 5.0/56381/56402; en-US 85
