3 Connecting the Camera
What is PoE+?
PoE (Power over Ethernet) is a technology that allows Ethernet cables
to carry electrical power to connected devices. High-powered devices
such as PTZ cameras use PoE+ (also known as PoE class 4 or IEEE
802.3at), which provides more power to connected devices than
standard PoE. Compatible NVRs use integrated PoE+ ports to pro-
vide power and PTZ commands to the camera, as well as video con-
nection to the NVR. PoE+ ports will provide up to 30W to each
connected device, whereas standard PoE (class 3) ports only provide
up to 15W. In order to use this PoE+ rated camera without a power
adapter, you must connect it directly to a compatible NVR (Compati-
ble with the LNR / NR / LNK Series NVRs, excluding the LNR200 and
LNR300 Series) or a PoE+ switch on the same network as the NVR.
PoE+ switches are available for purchase on
lorextechnology.com (model #: ACCLPS241B (4–channel model)
or ACCLPS281B (8–channel model)).
Complete the following steps to connect the camera to the NVR over
the LAN.
#; r. 4.0/47037/47040; en-US 6
