54
Technical specifications
Technical specifications
General
Description Specification
Transmission Frequency 2,400~2,483.5MHz
Transmission Power 16dBm
Unobstructed Effective
Range
650ft / 200m (line of sight)
Spread Spectrum FHSS
Modulation Mode GFSK
Operating Temperature 14 ~ 122° Fahrenheit / -10 ~ +50° Celsius
Operating Humidity < 85
%
Camera
Description Specification
Image Sensor 1/4" CMOS Image Sensor
Resolution 640 x 480pxl (NTSC)
Minimum Illumination 0Lux (IR on)
Night Vision Distance 40ft (12m)
PIR Range 21ft (6.5m)
View Angle Diagonal 52°
Power Consumption (Max.) Max 460mA
Power Supply 9V DC
Dimensions W: 75mm, L: 110mm, H: 190mm
Weight 0.60lbs / 0.27kg
LCD receiver
Description Specification
Display 9" diagonal or 7" diagonal (check package for display size)
LCD Resolution 800x480
Receiving Sensitivity -81dBm
Power Consumption (Max.) 7" Model: 950mA
9" Model: 1050mA
Power Supply 5V DC
Dimensions 7" Model: W: 42mm, L: 201mm, H: 150mm
9" Model: W: 42mm, L: 254mm, H: 202mm
Weight 7" Model: 1.55lbs / 0.70kg
9" Model: 1.00lbs / 0.44kg
