the lamp for about 4 seconds following ignition switch on, but if
the lamp then remains lit, or lights after washer use, refill the
reservoir at the first opportunity.
The windscreen washer heated jets are mounted each side of
the wiper spindle, and may, if necessary, be cleared or adjusted
using a suitable pin.
With ignition and headlamps on, the headlamp powerwash will
be activated for a short burst at the first, and every subsequent
fifth request of the screen wash switch. Cycling of either the
ignition or headlamp switch will reset this timing.
Wiper Blade
To replace the single wiper blade, open the front body access
hatch to allow the arm to be lifted fully away from the wind-
screen. Swing the blade through 90° and slide off the pivot pin
on the arm.
Servicing & Maintenance
Wiper blade
Wiper arm Rotate to
release
ohe26
