Rear Fusebox
Fuses for the engine bay and rear mounted systems are con-
tained in a fusebox mounted in the cabin, behind the left hand
rear quarter trim panel. For access, use a coin to release the
quarter turn fastener on the lower edge of the removable panel,
and unhook the top edge.
Fuse colours
2A - Black 5A - Orange 15A - Light blue
3A - Violet 7.5A - Brown 20A - Yellow
4A - Pink 10A - Red 25A - Clear
Electrical
Slot Rate Circuit
MR1 30A Crank & main rly.
MR2 30A Busbar R17-R20
Slot Rate Circuit
R11 7.5A A.c. compressor
R12 5A Rev lamp, camera
R13 -
R14 10A Engine bay cooling
fan (if used)
R15 3A Boot lamps
R16 10A Boot pwr. socket
R17 20A Amplifier
R18 5A Fuel filler flap
R19 10A Fuel pump
R20 5A Alternator B+
Slot Rate Circuit
R1 10A ECU, fan relay 3
R2 7.5A Injectors
R3 10A Ignition coils
R4 2A Re-circ. pump
R 5 -
R6 -
R7 5A ECU ignition
R8 7.5A Engine solenoids
R9 5A O2 heaters
R10 5A Alternator ign.
