Fuses
The main fuseboxes are located at the front of the passenger
footwell, protected by a removable panel secured by a quarter
turn fastener at each top corner, and a location channel on the
floor.
Forty slots are provided for mini fuses which are numbered,
and coloured according to their amperage rating, and may be
pulled out from their slots using the fuse extractor tool clipped
to the fusebox. Six maxi fuses protecting major circuits are also
provided.
WARNING
Replacing a fuse with one of a higher rating may cause extensive
damage to the electrical system and possibly cause a fire. If a
fuse of the correct rating is not available, use one of a lower
rating as a temporary measure.
Electrical
Slot Rate Circuit
C21 3A Ign. services
C22 5A ABS
C23 3A Homelink
C24 3A Brake lamps
C25 15A HL powerwash
C26 5A Alarm ignition
C27 -
C28 7.5A HVAC ignition
C29 7.5A Heated Washer
jets
C30 5A SRS unit
C31 3A Heated mirrors
C32 5A Washer pump
C33 5A Mirror/window sw.
C34 20A Wiper motor
C35 20A Interior fan
C36 10A Cabin pwr. socket
foward
C37 10A Cabin pwr. socket
rear
C38 25A Heated rear screen
C39 10A LH heated seat
C40 10A RH heated seat
Slot Rate Circuit
C1 10A Horn
C2 5A Battery services
C3 7.5A CDL, Alarm B+
C4 20A Rad fan relay 1
C5 20A Rad fan relay 3
C6 10A Radio B+
C7 5A Key-in relay
C8 2A Ignition switch
C9 20A Driver’s window
C10 20A Pass. window
C11 7.5A Hazard & Turn
C12 3A Interior lighting
C13 20A Int. control mod.
C14 3A Footwell lamps
C15 5A LH sidelamps
C16 5A RH sidelamps
C17 15A LH headlamp
C18 15A RH headlamp
C19 15A Main beam
C20 3A Not used
