Electrical
4. Each headlamp assembly features a single vertical alignment
adjustment screw positioned to the outboard top of the lamp.
Turn clockwise to raise the beam, or counterclockwise to lower.
Optimum setting is -1.2%.
5. Repeat for the opposite lamp.
Note that there is no adjustment for lateral alignment.
6. Re-fit the access cover in the wheelarch liner.
