Capacities
Evora
Engine oil (refill inc. filter) 6.1 litre
High/low dipstick mark difference
1.5 litre
Evora S
Capacity - refill inc. filter*: 10.1 litre
(*Engine oil capacity is 6.1 litres but supercharged cars fitted with
front mounted oil coolers contain an additional 4 litres of oil. This
oil is not drained during routine servicing)
High/low dipstick mark difference
1.5 litre
Transmission oil 2.3 litre
Brake & clutch system 580 cc
Power steering system (PAS) 1.5 litre
Cooling system 17 litre
A.C. refrigerant (R134a) 0.625 kg
Windscreen washer bottle 7 litre
Fuel tank 60 litre
Front Suspension
Type Independent. Upper and
         lowerwishbone;co-axial 
         coilspring/telescopicdamper;
anti-roll bar.
Alignment - optimum 0°
- tolerance range 0.5 mm toe-out, to
0.5mm toe-in overall
Rear Suspension
Type Independent. Upper and
         lowerwishbone;co-axialcoil
         spring/telescopicdamper;toe-
         link;anti-rollbar.
Alignment - optimum (Evora) 0.36° total
- tolerance range 1.4 to 1.8 mm toe-in each side
max. side/side 0.3 mm
Alignment - optimum (Evora S) 0.6° Total
- tolerance range 1.4 to 1.8 mm toe-in each side
max. side/side 0.3 mm
Technical Data
176
