Operation Instruction
Combination instrument
Fig.3-2 Combination instrument
1. Fuel gauge 2. Water temperature gauge 3. Tachometer 4. Timer 5. Oil pressure gauge 6.Ammeter
Fig.3-2 Combination instrument
Important: During tractor worki
ng, the driver should take note all kinds of instruments and indicators. If
abnormal, please immediately park and repair.
Left side rocker switch combination
Warning Indicator System Table for Combination Instrument
Left turn signal
High beam
Low beam
Oil pressure indicator
Small lamp
Air brake
18
