Operation Instruction
Fig.3-3 Left side rocker switch combination
Turn signal switch
Position “1”: switch on the
left turn signal lamp; Position “0”: power off; Position “2”:
switch on the right turn signal lamp.
Fig.3-4 Turn signal switch
Switch for work lamp
“0”: Power off ; “1”: Position lamp on ; “2”: position lamp and backup lamp on
Fig. 3-5 Switch for work lamp
Right side rocker switch combination
Fig.3-6 Right side rocker switch combination
1 Dimmer switch;
2 Hazard warning switch;
1 Switch for direction lamp；
2 Switch for work lamp
19
