Lowrance HOOK2 X series User Manual

Edit overlay data
On models with GPS, you can have up to 3 data overlays on the
GPS , sonar and DownScan (available on 5x and 7x models only)
pages. Use the Edit overlay option on the System Controls dialog to:
• Change a selected data overlay to display different data.
• Select a predefined size from the size drop-down list.
• Select the OFF option in the predefined size drop-down list to
remove the selected data overlay from the page.
On 4x Sonar only models, you can have up to 3 data overlays on the
sonar page. Use the Edit overlay option on the System Controls
dialog to:
• Select a predefined size from the size drop-down list.
• Select the OFF option in the predefined size drop-down list to
remove the selected data overlay from the page.
Stop sonar
Select the Stop sonar option in the System Controls dialog to stop
all sonar from pinging. Use the stop sonar option anytime you want
to disable all sonar but not power off the unit.
Basic operation | Hook² X Series Operator Manual
13

Lowrance HOOK2 X series Specifications

General

Waterproof Rating	IPX7
Water Resistance	IPX7
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Wi-Fi	No
Bluetooth	No
Display Resolution	480 x 272 pixels
Sonar Frequency	200 kHz
Power Output	200W RMS
Depth Capability	500 ft (152 m)
Storage Temperature	-20°C to +60°C
Transducer	Included
Display Size	4" or 5" or 7" (depending on model)
Sonar	Broadband Sonar
DownScan Imaging	Available on some models
GPS	Yes (on select models)
