Lowrance HOOK2 X series User Manual

DownScan
Ú
Note: DownScan is available on 5x and 7x models only.
DownScan provides detailed images of structure and fish directly
below your boat, down to 91 m (300 ft) at 455 kHz and 46 m (150 ft)
at 800 kHz.
The DownScan image
2
1
1 Data overlay
2 Range limit
Zooming the DownScan image
You can zoom a DownScan image by using the Zoom keys.
Customize the image settings
By default the unit is set to Auto mode, and most settings are
automated. It is recommended that only experienced sonar users
use the customize settings to further customize the sonar image.
Select Auto in the menu and change to custom mode to customize
image settings.
8
28
DownScan | Hook² X Series Operator Manual

Lowrance HOOK2 X series Specifications

General

Waterproof Rating	IPX7
Water Resistance	IPX7
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Wi-Fi	No
Bluetooth	No
Display Resolution	480 x 272 pixels
Sonar Frequency	200 kHz
Power Output	200W RMS
Depth Capability	500 ft (152 m)
Storage Temperature	-20°C to +60°C
Transducer	Included
Display Size	4" or 5" or 7" (depending on model)
Sonar	Broadband Sonar
DownScan Imaging	Available on some models
GPS	Yes (on select models)
