Lowrance HOOK2 X series User Manual

Contents
9 Introduction
9
Front controls
10 Application pages
11 Basic operation
11 System Controls dialog
11 Settings
12 Turning the system on and off
12 Display illumination
12 Data Overlay
13 Stop sonar
14 GPS plotter
14 GPS plotter page
15 Vessel symbol
15 GPS plotter page scale
15 Panning the GPS plotter image
15 Positioning the vessel on the page
16 Waypoints, Routes, and Trails
16 Navigating
16 GPS plotter settings
18 Waypoints, Routes, and Trails
18 Waypoints, Routes, and Trails dialogs
19 Waypoints
20 Routes
20 Trails
20 Editing waypoints, routes and trails
22 Navigating
22 Navigate to cursor position
22 Navigate to a waypoint
22 Navigate a route
23 Sonar
23 The Sonar image
24 Zooming the image
Contents | Hook² X Series Operator Manual
7

Lowrance HOOK2 X series Specifications

General

Waterproof Rating	IPX7
Water Resistance	IPX7
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Wi-Fi	No
Bluetooth	No
Display Resolution	480 x 272 pixels
Sonar Frequency	200 kHz
Power Output	200W RMS
Depth Capability	500 ft (152 m)
Storage Temperature	-20°C to +60°C
Transducer	Included
Display Size	4" or 5" or 7" (depending on model)
Sonar	Broadband Sonar
DownScan Imaging	Available on some models
GPS	Yes (on select models)
