Lowrance StructureScan 3D User Manual

The 2D image
The 2D image is the default view when the StructureScan module is
connected to the display.
The 2D view is displayed when the 3D menu option is not selected.
SideScan Left+Right
DownScan
1 Depth
2 Temperature
3 Frequency
4 Range scale
Ú
Note: The 2D image examples are from the NSS evo2. On
HDS Gen3 images the range scale is located at the bottom
of the image, and temperature and depth overlay can be
placed in a user specified location.
3
The 2D image | StructureScan 3D User Guide
11

Lowrance StructureScan 3D Specifications

General

Brand	Lowrance
Model	StructureScan 3D
Category	Transducer
Language	English
