12
Stop Sonar
Stops Sidescan and Downscan sonar from the scrolling, allowing you to get a closer
look at onscreen objects or locations.
To pause/restart the chart, highlight Stop Sonar on the Structure menu and press
ENTER.
Log sonar
Records sonar logs, allowing you to review
sonar data later via an MMC or SD card.
To access the Sounder Logging menu, select
Log Sonar Data from the Structure menu and
press ENTER.
Log Sonar Menu
Filename
Input the desired name for the sonar log le
Save to
Selects location where sonar log will be saved/stored; to save
data to MMC/SD card, select Memory Card
Bytes
Controls number of bytes per sounding. More bytes yields
better resolution/shorter logging time; conversely, fewer
bytes produces longer sonar logs/lower resolution
Log All Channels
Logs StructureScan data and conventional sonar data
simultaneously. When logging all channels, logs are saved
in.Sl2 format instead of .slg format. The .Sl2 le format is
not compatible with non-HDS units.
Time Remaining
Recording time left until memory storage runs out
To input a lename:
Highlight the Filename text box and 1.
press ENTER. A keyboard will appear
on the screen.
Use the keypad to input the desired 2.
lename.
Select 3. OK and press ENTER.
To Next Page
